Products Description
A crane mounted on a truck carrier provides the mobility for this type of crane. This crane has two parts: the carrier,often referred to as the Lower, and the lifting component which includes the boom, referred to as the Upper. These are mated together through a turntable, allowing the upper to swing from side to side. These modern hydraulic truck cranes are usually single engine machines, with the same engine powering the undercarriage and the crane. The Howo Self Loader Truck Crane upper is usually powered via hydraulics run through the turntable from the pump mounted on the lower. In older model designs of hydraulic truck cranes, there were two engines. One in the lower pulled the crane down the road and ran a hydraulic pump for the outriggers and jacks. The one in the upper ran the upper through a hydraulic pump of its own. Many older operators favor the two-engine system due to leaking seals in the turntable of aging newer design cranes.
Products Parameters
| HOWO 8x4 Chassis Specification | ||||||
| General | Chassis Model | HOWO | ||||
| Overall dimension(L*W*H) | 12200x2550x3950mm | |||||
| Chassis | Drive modle | 8x4 Left Hand Drive or Right hand Drive | ||||
| Wheel Base | 1800+4600+1350 mm | |||||
| Transmission | HW19710, 10-Forwards & 2-Reverses | |||||
| Axles | HF9/HC16 | |||||
| Fuel Tank | 400L | |||||
| Tyre size & No. | 12.00R20, 12pcs | |||||
| Engine | Model | SINOTRUK WEICHAI | ||||
| Horsepower | 400 HP | |||||
| Displacement | 9.726L | |||||
| Emission Norm | Euro 2 | |||||
| Type | 6 cylinders in line, water cooled, four strokes, turbo-charged intercooling | |||||
| XCMG Boom Crane Specification | ||||||
| Crane Model | SQZ330 | Max. lifting Capacity | 16 tons | |||
| Arm Number | 6 telescopic arms | Rotation Angle | 360° all Rotation | |||
| Type of Crane | Folding-arm crane | Max working radius | 12.1m | |||
| Remote Control | Equipped | Max lifting altitude | 14m | |||
| High Chair | Equipped for operation | Front Supporting Legs | Equipped | |||
| Cargo Sidewall Length | 8m or above | Cargo Sidewall Height | 600mm or above | |||
Sinotruk HOWO classical cabin
XCMG brand SQZ330 model 12tons boom crane
Boom crane hydraulic control valve
Hydraulic oil cooling radiator
Customized 7m cargo body
Customized 7m cargo body
Heavy type towing winch 8tons
HOWO RHD truck cabinet
| Model | SQ16ZK4Q | Unit | ||||
| Max Lifting Moment | 40 | t.m | ||||
| Max Lifting Capacity | 16000 | kg | ||||
| Recommend Power Needed At Recommend Oil Flow | 37 | kw | ||||
| Max Oil Flow of Hydraulic System | 63 | L/min | ||||
| Rated Pressure Of Hydraulic System | 31.5 | MPa | ||||
| Oil Tank Capacity | 250 | L | ||||
| Rotation Angle | (360°) All Rotation | |||||
| Crane Weight | 5000 | kg | ||||
| Installation Space | 1500 | mm | ||||
| Choice of Chassis | ISUZU GIGA, HOWO, BEIBEN, FAW, SHACMAN, JAC,IVECO, etc | |||||
| SQ16ZK4Q Lifting capability diagram | ||||||
| Working radius(m) | 2.5 | 4.098 | 5.898 | 7.748 | 9.618 | 11.518 |
| Lifting capacity(kg) | 16000 | 9600 | 6600 | 4850 | 3500 | 2600 |
CS TRUCKS Self Loader Truck Crane advantages
Knuckle boom cranes are an amazing piece of engineering technology. Also called a loader crane, articulating crane, and a picker crane, the knuckle boom crane has changed the way people load and offload in a variety of industries. It looks similar to the traditional straight boom crane, but the knuckle boom crane has two booms; a main boom and an outer boom. These two booms have a knuckle between them, which allows more options for the loader crane operator.
Look at your fingers; hold your index finger out straight, and then bend your finger at the knuckles. The knuckle boom crane works in the same manner. The addition of these two knuckles on the crane allows for many more different uses compared to a straight boom crane. These knuckles also make it easier to fold into a smaller size, but at the same time it can extend further to reach loads at a distance. This kind of "fold and extend" ability is missing in the traditional stiff boom cranes.
