Beiben 1929 sewage suction tanker truck (also known as vacuum sewer truck, cesspit emptier truck, or industrial sludge collector) is engineered for waste handling including septic tank cleaning, municipal sewage extraction, and industrial sludge collection. With 12000L capacity and 290HP power, its 4×2 chassis delivers stable performance across urban operations, providing reliable waste solutions for modern municipal and industrial needs.
The effective volume of the vacuum tank is 12000 liters, utilizing 6mm thick carbon steel as the primary construction material. The tank structure employs optimized cylindrical design. The Beiben sewage suction tanker truck is equipped with professionally engineered vacuum pump systems, control mechanisms, and waste handling equipment.
*Congo Beiben 1929 Sewage Suction Tanker Truck*
-----------------------------------------------------------------
CS factory is professional manufacturer in truck area,
guarantee all products Brand-New and High-Quality.
» I.Product Defination and Introduction:
Manufacturer: CS TRUCKS
Features:
▶ Chassis: Based on Beiben 4×2 chassis, with 290HP diesel engine
▶ Tank Volume: Vacuum tank capacity 12000 liters
▶ Tank construction: Tank made of 6mm thick carbon steel
▶ Suction System: Installed at rear of the vehicle, with vacuum power
▶ Operation Scope: Suitable for septic tank cleaning, municipal sewage extraction, and industrial sludge collection
» II. Product Parameters for Beiben 12 CBM Sewer Jetter Truck
| Product Name | Congo Beiben 1929 Sewage Suction Tanker Truck | ||
| Overall | Vehicle Model | CS5190GXW | |
| Drive Type | 4*2 | ||
| Gross Vehicle Weight | 19000 kg | ||
| Curb Weight | 10300 kg | ||
| Maximum Speed | 100 km/h | ||
| Overall Dimensions L*W*H | 8200*2550*3150 mm | ||
| Engine | Engine Model | WP10.290E32 | |
| Engine Brand | Weichai | ||
| Fuel Type | Diesel | ||
| Power | 290 HP(213 KW) | ||
| Emission Standard | Euro III | ||
| Displacement | 9726 ml | ||
| Engine Type | 6 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling | ||
| Chassis | Chassis Brand | Beiben | |
| Tire No. | 6+1 | ||
| Tire Specification | 12.00R20 16PR | ||
| Wheelbase | 4800 mm | ||
| Gear Box | FAST 9JS150A, 9-speed forwards and 1 reverse | ||
| Steering Wheel | Left hand drive | ||
| Brake | Air brake | ||
| Radiator | Suitable for tropical climate | ||
| Superstructure | Vacuum Tank | ||
| Tank Volume | 12000 Litres | ||
| Tank Shape | Cylindrical | ||
| Tank Material | 6mm thick carbon steel | ||
| Suction Hose | 10 meters, DN100 | ||
| Discharge Valve | DN100 | ||
| Lifting Angle | 45° | ||
| Vacuum Pump | |||
| Brand | Wloong (China famous brand) | ||
| Model | 68/7000 | ||
| Ultimate Pressure | 7000 pa | ||
| Pumping Speed | 68 L/s | ||
| Maximum Vacuum | 93% | ||
| Rotation Speed | 800 rpm | ||
» III. Products Description:
1. Chassis Configuration:
♦ The robust chassis is rated for a gross vehicle weight of 19,000 kg, with a curb weight of 10,300 kg, providing a substantial payload capacity for heavy-duty sewage transport.
♦ FAST 9JS150A 9-speed transmission with 4800mm wheelbase configuration provides reliable power transmission for continuous waste handling cycles.
2. Powertrain System
♦ WP10.290E32 inline 6-cylinder turbocharged diesel engine delivers 290HP peak power, meeting Euro III emission standards with 9726ml displacement.
♦ FAST 9JS150A 9-speed transmission with 4×2 drive system and 4800mm wheelbase chassis configuration provides stable power transmission for sewage suction operations under varied working conditions.
3. Core Hydraulic Command Valve
♦ This valve centrally controls the Wloong high-performance vacuum pump (68 L/s flow rate) and the 45-degree dumping system, managing the entire workflow from suction to discharge.
♦ It ensures efficient power transfer and precise hydraulic coordination, forming the essential control hub for this powerful sanitation solution.
4. Rear Door Safety Chain
♦ Features a manual handle for quick open/close operation and a wear‑resistant valve body, often with quick‑connect fittings for efficient hose coupling.
♦ Positioned at the tank bottom as the key outlet component, it ensures efficient and complete waste evacuation after the suction process.
» IV. Beiben Suction Truck Operating Principle:
♦ Power Drive: Driven directly by the truck's PTO, powered by the 290HP Weichai engine, to generate high vacuum.
♦ Core Performance: Delivers a pumping speed of 68 L/s with an ultimate vacuum degree of 93%, enabling rapid and thorough suction.
♦ Design & Integration: Engineered as a key component of the 12000L tank system for high‑frequency municipal and industrial sewage operations.
♦ Function: Provides the essential suction force for efficient waste extraction in septic, sewage, and sludge handling scenarios.
| Wloong 68/7000 Vacuum Pump Specifications | |
| Model | 68/7000 |
| Application | For heavy-duty vacuum tank trucks |
| Brand | Wloong |
| Weight | 65 kg |
| Drive Model | PTO |
| Transport medium | Air |
| Power | 5 kw |
| Ultimate pressure | 7000 pa |
| Pumping speed | 68 L/s |
| Rotating speed | 800 r/min |
| Outlet | 50 mm |
| Max working temperature | 85℃ |
Product Details
12 CBM Carbon Steel Vacuum Tank
DN65 Aluminum Alloy Suction Valve
6mm Plexiglass View Window
Beiben Sewage Truck Driver's Cab
Anti-skid ladder on the driver's side
Beiben Sewage Truck Hydraulic Oil Tank
» V.Beiben Sewage Suction Tanker Truck Solutions:
Beiben Sucker Pumper Truck For Municipal Streets
Beiben Sewer Vacuum Sucker Truck For Rivers
Beiben Septic Tank Truck For Mining Sites
Beiben Sewage Tanker Truck For Industrial Parks
» VI. Beiben Sewer VacuumTruck Exterior Views:
Front Left View of Beiben Septic Tank Pump Truck
Left View of Beiben 12000L Sewer Jetter Truck
Rear Left View of Beiben 12 CBM Septic Pump Truck
Rear Right View of Beiben 12 CBM Septic Tank Truck
Front View of Beiben 12 CBM Sewage Pump Truck with NG80B cabin
Rear View of Beiben Septic Tank Pump Truck
Products--100% China Beiben factory trucks!
Shipping - 100% fast, Convenient, Efficient!
Guarantee - 7 days + 24 hours Safety Service!
1. Beiben 1929 Sewage Truck Chassis: Configured with 4KH1CN6HB diesel engine rated at 132HP + Beiben manual 6-speed transmission system, optimized for operational efficiency in urban transportation applications.
2. Vacuum Tank Structure: Manufactured from reinforced steel, featuring optimized structural construction with cargo dimension specifications, finished with specialized protective coating.
3. Core Suction & Hydraulic System: Custom-configured hydraulic assembly designed for material unloading operations, engineered to achieve effective tipping and controlled return performance.
4. Operational & Safety Equipment: Standardized hydraulic tipping configuration, with optional auxiliary systems including ABS braking, tropical climate radiator, and multifunctional instrument panel for enhanced operational versatility.
