Products Description
Isuzu wildland fire engine is a specialized firefighting vehicle designed for combating wildfires in rural and remote areas. It is specifically engineered to navigate through rugged terrain, such as forests and mountains, and deliver effective firefighting capabilities.
It is equipped with a powerful engine and a robust suspension system that enables it to maneuver over rough and uneven terrain. This allows firefighters to access areas that are typically inaccessible to conventional firefighting vehicles. The engine's high ground clearance and all-wheel drive system provide additional stability and traction when driving over obstacles or on slippery surfaces.
Technical specification
II. Technical data of ISUZU Fire Fighting Truck 700P Water tank 5000Liters Rescue Forest Fire
| Condition | New condition/Left or Isuzu 700P/4x2 | |||
| Chassis | Brand | ISUZU | ||
| Model | ELF 700P | |||
| Curb weight(kg) | 15750 | |||
| Wheelbase(mm) | 4175 mm | |||
| Dimensions(mm) | 5193*2500*3040 mm | |||
| Overhang (front/rear) (mm) | 1500/2500 mm | |||
| Wheel track (front/rear) (mm) | 2110/1830/1830 mm | |||
| Approach/Departure angle(°) | 15/11° | |||
| Axle Load(kg) | 5000/10000 | |||
| Max. driving speed(km/h) | 90 km/h | |||
| Clutch | Reinforced diaphragm clutch | |||
| Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
|||
| Steering Gear | Power steering, hydraulic steering with power assistance | |||
| Tire | Number | 10pcs with one spare tire | ||
| Specifications | 12.00R20 | |||
| Gear box | MLD , Manual type, 6 Forwards & 2 Reverses | |||
| Cabin | Four doors and it can hold 8 fire fighter and 1 driver. With Air conditioner | |||
| Engine | Brand | ISUZU | ||
| Model | 700P | |||
| Fuel type | Diesel | |||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |||
| Displacement(ml) | 9726 ml | |||
| Power(kw) | 139 kw | |||
| Horsepower(HP) | 190 HP | |||
| Emission standard | Euro 5 | |||
| Torque(N.m) | 1500 N.m | |||
| Upper & Fire Fighting System | ||||
| Water tank | Volume(CBM) | 6.0 CBM | ||
| Tank Material | Q235 Carbon steel | |||
| Foam tank | Volume(CBM) | 0.5 CBM | ||
| Tank Material | Q235 Carbon steel | |||
| Proportion control system | Foam vessel , proportioned equipment, water - entering pipe and liquid - out pipe etc | |||
| Fire pump | Type | Centrifugal pump | ||
| Model | CB20.10/30.60 | |||
| Flow(L/s) | 60 | |||
| Pressure(Mpa) | 1 | |||
| Fire fighting pump Suction depth | ≥ 7 m | |||
| Fire fighting pump Suction Time | ≤45 s | |||
| Fire cannon | Model | PL48 | ||
| Flow(L/s) | 48 L/s | |||
| Water Range(m) | ≥55 m | |||
| Foam Range(m) | ≥50 m | |||
| Swing angle | Horizontal | 360 ° | ||
| Tilt angle | -30°~80° | |||
Advantage
ISUZU ELF cabin
Isuzu classic 700P front cabin
Coupling system
easy to use in emergency situation
Pipe
super reliable in operation
Manual system
English version and any version up to customer
Fire accessories
Reliable fire accessories
Fire pump
CB10/40, 10/60 model
Fire canon
360 degrees rotate
Fire pipe
High standard rubber
The usage of isuzu wild land engine ?
The Isuzu wildland fire engine is a vehicle specially used for fire extinguishing. Its purpose and functions can be summarized in the following five points:
1. Fire extinguishing of burning materials: Isuzu wildland fire engine is mainly used for fire extinguishing work, and can effectively control and extinguish burning materials, including forest fires, wildfires and grassland fires. It is equipped with a high-pressure water gun and nozzle, which can quickly spray a large amount of water or fire extinguishing agent to eliminate the source of fire and control the fire.
2. Control and monitoring of burning materials: In addition to the fire extinguishing function, the Isuzu wildland fire engine also has the ability to control and monitor burning materials. It is equipped with an advanced fire monitoring system and high-definition cameras that can monitor smoke, flames, temperature and other indicators in real time to provide fire fighters with accurate information and guidance.
3. High mobility and adaptability: Isuzu wildland fire engine has a small body size and strong off-road capabilities, and can maneuver under complex terrain conditions and enter narrow or rugged areas such as forests, mountains and canyons. It also comes with a four-wheel drive system and special large-diameter tires for better traction and handling.
4. Multi-functional tool: In addition to its fire-extinguishing function, the Isuzu wildland fire engine can also serve as a multi-functional tool for tasks such as road clearing, medical rescue and material transportation. It is equipped with lights and tool boxes, which can provide sufficient lighting and storage space to facilitate firefighters to perform tasks and prepare supplies.
5. Remote combat and collaborative work: Isuzu wildland fire engine also has the capability of remote combat and collaborative work. It is equipped with wireless communication equipment and satellite navigation systems, which can transmit data and information in real time, coordinate and communicate with the command center and other rescue personnel, improve firefighting efficiency and ensure safety.
