Products Description
The characteristics of Isuzu giga foam fire trucks, Foam fire trucks Isuzu are often used in fire response to urban buildings and residential areas. When a fire occurs in high -rise buildings or large residential areas, it is difficult for conventional fire extinguishing equipment to deal with the huge and burning situation of the fire. The Japan Isuzu giga foam fire truck is equipped with large -capacity water tanks and foaming installations, which can quickly spray the foam to the fire scene to form a fire -extinguishing barrier with a fast response and good closedness. This can not only effectively control the fire, but also reduce fire diffusion and material losses.

Isuzu Foam fire fighting truck can be divided into several types:
1--According to vehicle size, there are Isuzu mini fire fighting truck,light fire fighting truck Isuzu NPR,Isuzu medium fire fighting truck, heavy-duty fire fighting truck Isuzu.
2--According to chassis drive type, there are 4X2 or 6-wheel fire fighting truck, 6X4 or 10-wheel fire fighting truck, 8X4 12-wheel fire fighting truck and off-road type 4X4, 6X6 fire fighting truck for military use.
3--According to chassis brand, there are ISUZU giga fire fighting truck, Dongfeng fire fighting truck, Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Benz fire fighting truck, MAN fire fighting truck,SHACMAN fire fighting truck and so on.
4--According to fire extinguishant,there are water tank fire fighting truck Isuzu, dry powder fire fighting truck, water/foam fire fighting truck
5-There are also fire rescue truck with special purpose as follows,
--Foam supply fire truck;
--Compressed air supply fire fighting truck;
--Water tower fire truck ;
--Earthquake rescue fire truck;
Key Features
----► Original Isuzu Giga Fire truck chassis
----► ISUZU 6WG1-TCG51 diesel engine
----► CB10/60 pump & PS50 monitor
----► 20 years Fire truck manufacturing and design
----► High standard crew cabin
----► Full fire fighting rescue equipment
technical parameters
Spec. of Isuzu Giga Emergency Rescue 10Tons Water Foam Combination fire fighting truck
| Model | Parameters | others |
| Overall Dimension | 9965*2500*3750mm | |
| GVW | 26100kg | |
| Engine Model | ISUZU 6WG1-TCG60 | |
| Engine Power | 309kW | |
| Wheelbase | 4600+1370mm | |
| Driving Type | 6×4 | |
| Max.speed | 105km/h | |
| Emission Standard | 15730ml/kW | Euro6 |
| Fire pump rated flow | 60L/s@1.0Mpa, 30L/s@2.0Mpa | Vacuum pump |
| water monitor rated flow | 48-64L/s@1.0-1.2Mpa (ajustable) | Straight stream/spray/mist spray |
| Water monitor range | Water range≥65m,Foam≥60m | |
| Passengers | 2+4 | |
| Approach angle | ≥16° | |
| Departure angle | ≥19° |
| Item Parameters | Parameters | others | |||
| 1 | Tank capacity | water | ≥10000 | ||
| Foam | ≥2000 | ||||
| Dry powder | NIL | ||||
| 2 | Fire pump model | CB20.10/30.60 | Shanghai rongshen | ||
| 3 | Fire pump performance | Pressure 1:1.0Mpa flow:60L/S Pressure 2: 2.0Mpa flow:30L/S |
Use vacuum pump to priming water | ||
| 4 | the installation site of fire pump | rear | |||
| 5 | The quantity of fire pump water outlet | 6 | |||
| Dry powder tank pressure | 0.5Mpa~1.7Mpa | ||||
| 6 | Pressure gauge | 0-2.5 MPa | 2.6 level | ||
| 7 | Vacuum gauge | -0.1- -1 MPa | 2.6 level | ||
| 8 | Water monitor (PL48-64) |
Injection pressure | water:≥65m Foam: ≥60m |
Zhangqiu | |
| 1.0~1.2Mpa | |||||
| Depression/Elevation angle | -15-+75° | ||||
| Turning angle 340° | |||||
| 9 | Foam proportioner | 3%-5% | |||
| 10 | PTO Model | YTQ800F type full power sandwich , pneumatic | |||
Truck detail




Fire fighting equipment on board
| Item | Item | parameters | unit | quantity |
| 1 | sucking hose(DN135) | Φ135×2m | piece | 4 |
| 2 | water filter(FLF135) | Φ135 | piece | 1 |
| 3 | Water collector | FJ135 | piece | 1 |
| 4 | Adapter | kJ65/80 | piece | 2 |
| 5 | Adapter (KT135) | 135 to 100mm | piece | 1 |
| 6 | sucking pipe wrench | FS135 | piece | 2 |
| 7 | fire hydrant wrench | FB400 | piece | 1 |
| 8 | underground fire hydrantwrench | FBA1000 | piece | 1 |
| 9 | water hose | 20-65-20m | disc | 8 |
| 10 | water hose | 20-80-20m | disc | 4 |
| 11 | straight stream nozzle | QZG19 | piece | 1 |
| 12 | diversion spray nozzle | QZH19 | piece | 1 |
| 13 | Foam nozzle | PQ8 | Piece | 1 |
| 14 | Foam nozzle | PQ16 | piecec | 1 |
| 15 | Water distributor | FFS80 | piece | 1 |
| 16 | hose protector | HQ600(wooden) | pair | 2 |
| 17 | Fire spade | Piece | 1 | |
| 18 | Fire crowbar | piece | 1 | |
| 19 | hose hook | FG600 | piece | 2 |
| 20 | hose gaiter | FP470 | piece | 4 |
| 21 | fire axe | 817mm | piece | 1 |
| 22 | pickax | piece | 1 |

Factory production

How to maintenance your Fire pump
Q: How to maintenance your fire pump?
