Products Description
Sewage cleanup is an important process that helps keep communities safe and clean. This must be done regularly throughout the year to prevent sewer pipes from getting clogged. At this time, the sewage suction truck comes in handy. Sewage suction trucks are essential tools for removing sludge and sewage. It is a commercial truck with vacuum tank, pump and suction hose on it.
ISUZU sewage suction truck has large tonnage, high efficiency, multiple functions, simple and flexible operation. The tank head is die-cast in one step, the tank can be self-unloaded, and the back cover can be opened hydraulically. The sewage in the tank can be poured directly through the back cover. It adopts high-quality water circulation vacuum pump with large suction power and long suction range. It is suitable for pumping feces, sewage, sludge and liquids mixed with small suspended solids. It is the first choice vehicle for collecting, transferring, cleaning and transporting sludge and sewage to avoid secondary pollution.
Products specifications
|
Vehicle description |
|||
| Vehicle Name | ISUZU mini sewage suction truck | ||
|
Overall Dimension mm (LxWxH) |
6,720×2,050×2,500 (mm) |
||
|
Max.Weight |
11,000 (kg) |
||
|
Curb weight |
4,150 (kg) |
||
|
Suction tanker description |
|||
|
Tanker |
Capacity |
5,000L |
|
|
Material |
High quality carbon steel,Q235 |
||
|
Thickness |
6mm for tanker body and rear cover |
||
|
External tank treatment |
Rust proofing treatment as standard |
||
|
Structure |
Machine welding automatically, cylindrical tank |
||
|
Hydraulic dump system |
The tank lift angle could be higher up to 45° |
||
|
Rear door hydraulic open |
|||
|
Painting and logo |
As required |
||
|
Vacuum pump |
Brand |
YIFENG |
|
|
Model |
SK-12 |
||
|
Pumping rate |
12CBM/min |
||
|
200 L/S |
|||
|
Max speed |
970 r/min |
||
|
Max pressure |
8000 pa |
||
|
Suitable |
5,000Liter |
||
|
Standard Specs |
PTO |
Equipped |
|
|
Gear pump |
China famous brand |
||
|
Multi-way valve |
Equipped |
||
|
Hydraulic cylinders |
4sets |
||
|
Liquid level view pipe |
Standard |
||
|
Liquid level alarm device |
Standard |
||
|
Anti-overflow valve |
Standard |
||
|
Suction hose |
Standard 8 meters |
||
|
Drain valve |
Standard |
||
|
Chassis Description |
|||
|
Chassis brand |
ISUZU |
||
|
Chassis condition |
Brand new - year of 2023 |
||
|
Cab |
Single cabin, 2 doors |
||
|
3 seats with A/C |
|||
|
Driving type |
Left hand driving, 4x2 - 6wheeler |
||
|
Tire |
7.50R16 tire, 6+1(pcs) |
||
|
Engine |
Brand |
ISUZU - 4KH1CN5HS |
|
|
Fuel |
Diesel |
||
|
Emission standard |
Euro V |
||
|
Displacement |
3000cc |
||
|
POWER |
130hp / 96kW |
||
|
Number of cylinders |
4 |
||
|
Maximum torque |
290 N.m at 1500-1900rpm |
||
|
Gear box |
Brand |
ISUZU - MSB |
|
|
Number of gears |
5 Forwards gear & 1 reverse gear |
||
|
Axle |
Front |
2.5T |
|
|
Rear |
4.8T |
||
|
Brake System |
Oil brake and vacuum booster pump |
||
Products features
1. The tank body is rolled and formed from 6mm thick high-quality steel plate, which is strong and durable.
2. The tank body is automatically welded by machine
3. Equipped with water circulation vacuum pump, with large suction power and long lift
4. The inside of the sewage suction tank is pickled and an epoxy resin anti-corrosion coating is added to increase the service life of the tank.
5. Detachable transparent observation tube for easy cleaning and replacement
6. Chinese brand high-quality multi-way valve with high precision and stable operation
