Products Description
When major natural disasters such as floods or earthquakes occur, bridges and roads are vulnerable to damage, resulting in large fire trucks unable to enter the disaster scene as soon as possible. At this time, rescue workers need to carry professional equipment on foot to carry out rescue operations.
However, in this way, the rescue efficiency is low on the one hand, and on the other hand, firefighters are also facing great risks. Therefore, it is particularly important to develop a mechanical and equipment that has strong obstacles, strong power, and multi-functional characteristics as large equipment and human rescue.
9988FAW 4×4 fire engine adopts a 4×4 AWD chassis, which solves the problem of poor cross -obstacle performance of conventional chassis, and meets the actual needs of emergency rescue and rapid response. It was able to send fire-extinguishing media, rescue equipment and personnel to the fire scene to start fire extinguishing work as soon as possible, which improved the fire extinguishing efficiency.
Products specifications
|
Cabin |
Double Row Cab with Air condition |
|
|
Driving type |
4×4, all wheel drive |
|
|
Vehicle Dimensions |
Overall dimensions (L x W x H)mm |
8000×2500×3200 |
|
Wheelbase (mm) |
3300mm |
|
|
Wheel track (front/rear) (mm) |
1660/1590 |
|
|
Weight in KGS |
Gross Vehicle Weight |
8200 |
|
Tare weight |
5200 |
|
|
Front axles loading capacity |
2500 |
|
|
Speed ratio |
5.571 |
|
|
Rear axles loading capacity |
5000 |
|
|
Speed ration |
5.571 |
|
|
Max. driving speed(km/h) |
90 |
|
|
Engine |
Brand |
YUCHAI |
|
Model |
YC4D130-33 |
|
|
Fuel type |
Diesel |
|
|
Type |
4-stroke direct injection , 4-cylinder in-line, water cooling |
|
|
Horse Power(HP) |
130 HP |
|
|
Emission standard |
Euro 3 |
|
|
Rated speed |
2800 rpm |
|
|
Max. torque |
420 N.m |
|
|
Gearbox |
WLD, 6 Forwards gear & 1 reverse gear |
|
|
Clutch |
Diameter 330mm |
|
|
Steering |
Power steering, hydraulic steering with power assistance |
|
|
Fuel tank (L) |
100 liters |
|
|
Tire |
7.50R16,7 pcs including one spare tire |
|
|
Tank Capacity (L) |
Water: 2,000 |
|
|
Foam: 1,000 |
||
|
Fire Pump |
Model |
CB10/30 |
|
Flow |
30L/s at Low Pressure 1.0 MPa |
|
|
Fire Monitor |
Model |
PL24 |
|
Pressure |
1.0~1.2MPa |
|
|
Flow |
24L/S |
|
|
Range |
Water≥55 m |
|
|
Foam≥45 m |
||
|
Rotation angle |
360° Horizontal |
|
|
-30°~80° Pitch Angle |
||
Products features
Features of FAW 4×4 fire fighting vehicle:
• Good driving force and driving performance: FAW 4×4 fire truck has good driving force and driving performance. Under various terrain and weather conditions, it can quickly reach the fire scene and effectively start rescue work.
• Complete fire equipment and functions: FAW off-road fire engine trucks are equipped with various fire equipment and functions, such as water tanks, foam tanks, dry powder fire extinguishers, fire water guns, fire pumps, etc. These devices have sufficient capacity and performance, which can quickly extinguish the source of fire at the fire scene and protect personnel and property safety.
• Good carrier and rescue capabilities: The fire truck also has good carrier and rescue capabilities, which can quickly launch rescue work at the fire scene. The vehicle has sufficient space and equipment, which can be equipped with sufficient firefighters and rescue workers, and equipped with necessary rescue tools and equipment.
• Good structural strength and safety: The vehicle has good stability and reliability, which can avoid failure or accident during driving or working.
