HOWO 4X4 Mobile Repair and Lubrication truck
HOWO 4x4 Off road mobile workshop Provide all tools and workshop equipment used for different areas. Tools for jaw, installation and installation, hand tools and electric suit for each Function for its intended purpose, various stream sources for all equipment, Lighting systems with high-capacity battery equipment for the longest period of time.
THE MOST EFFECTIVE WAY FOR MAINTENANCE AND REPAIR ON THE FIELD
Bodies are composed by a subframe with crossmembers and covered by chequered steel plates. Ceiling and drop sides are supported by a rigid steel frame. Drop sides and upper flaps are made of aluminium profiles and they ease the accessibility to operate and handle the equipment. The rear is also fitted with flaps or an hydraulic operated tailgate.
HOWO MOBILE WORKSHOPS FOR REPAIR AND ASSISTANCE
Equipment for emergency service, assistance, maintenance and repair of: earth moving machines, working site vehicles, agricultural machines, vehicles in general, fixed installations, mechanical equipment.
They can be installed on:
– Heavy vehicles used by construction companies in big foreign working sites, where the logistical conditions require a certain functional independence to ensure a prompt intervention for maintenance and repair of the operating machines
– Light vans easy to handle in case of emergency, polyvalent, and multifunctional, able to resolve and satisfy the requirements of vehicles dealers; municipal companies in charge of the distribution of gas, water, electricity; public and ministerial departments; and single users
All equipment are defined in close collaboration with the end user in view of his specific requirements, and could be homologated for road circulation.
Technical Specification
HOWO all drive mobile maintenance workshops are used for assignments that range from UN mission support to Private- and Commercial- organizations’ backing and maintenance services, e.g. on construction sites for road building or other remote temporary sites. The client-specific mobile workshops are fitted with modern, lightweight yet durable equipment and tools that enable to perform repairs of all types of vehicles, communication equipment and general purpose ancillary jobs.
HOWO mobile laboratories are used for everything from crime scene investigations and customs examinations to air & water quality measurement and environmental compliance analysis.
Expertise on exceptionally high standards
The robust, long-lasting vehicles and container systems have proved themselves time and time again. In each case, we apply our expertise in insulation, soundproofing, materials, vehicle dynamics and other relevant disciplines to meet the exceptionally high standards required.
Truck rigid chassis specs:
Brand: SINOTRUK HOWO
Driving type:4X2/4x4/6x4/6x6
Loading capacity: 10ton/16ton/25ton/30ton
Length of tray: 6/7/8/9 meters
Driver’s cab: Left Hand Drive/Right Hand Drive, AC
Engine :Sinotruk Diesel engine 290hp/336hp/371hp
Transmission: Sinotruk Manual transmission, HW15710/HW19710
Front Bridge:7ton/9ton
Driving Bridge:ST16
Tire:11R22.5/11.00-20/12.00-20/12.00R20/315R22.5
Customized workshop body:
-Side opening barn doors
-All exterior doors / cabinets fully lockable and keyed alike
-Dismountable Alumium and pull-out ladder to store in the tool chamber -or on the back tray.
-Led lighting interior, LED work lights exterior sides and rear. LED light bar or beacons LED
-Fully self contained box - so as could be removed from truck and used as self contained site workshop if needed in future
- Diesel 3-4 KW 240V generator
- Electric compressor
- Fuel storage tanks
- Secure area for 1 X 44 Gallon engine oil storage. Pneumatic Engine oil pump
- Compact cold water pressure cleaner - diesel powered - so can be removed from truck if / as required
- Storage cabinets / cages for spare parts , batteries etc
- Storage cabinets for tools
- Supply truck with HD high output alternator
- Battery isolator switch
|
Vehicle model |
HOWO 4x4 |
|
|
Drive type |
LHD，RHD |
|
|
Cabin |
HOWO |
|
|
Dimensions date |
Wheel base(mm) |
4500 |
|
Engine |
Model |
WP10.270E32,WP10.290E32 |
|
Emissions standards |
Euro 2 |
|
|
Horse power |
270hp, 290hp |
|
|
Fuel type |
Diesel |
|
|
Gearbox |
Model |
9JS150A |
|
Front axle |
Loading weight |
7.5T |
|
Rear axle |
Loading weight |
13T |
|
Wheels and tyre size |
6+1(12.00R20) |
|
|
Work Shop List |
|
|
Diesel Generator |
Cummins brand Diesel Generator with 20KVA,1 Phase,50HZ,230V, |
|
Air Compressor |
Air operated model 150psi, 10bar |
|
Lube filling System |
5X50Lt capacity each with pneumatic control pump with hose and filling gun(The max lube tank we can get is 50L ) with pneumatic |
|
Welding Machine |
gas welding machine X1 & gas cutting torchesX1 |
|
Arc Welding machine |
3 phase ( 500 Amps) X1 |
|
Washing Machine |
100 to 150 bar with water storage tank with safety placing bracket) |
|
Tire vulcanizing machine with work table. |
1set |
|
Pow distribution cabinet |
As our standard design |
|
Tool Cabinet |
As our standard Design with basic tools (Spanner, Wrench) light duty & heavy duty |
| DESCRIPTION | SPECIFICATIONS | QTY | PRICE |
| WORK BENCH L 1,50 m x W 750 mm x H 850 mm + 6 DRAWERS |
6 drawers: 4 x Width 569 x Depth 421 x Height 60 mm 1 x Width 569 x Depth 421 x Height 130 mm 1 x Width 569 x Depth 421 x Height 270 mm with drawers separations set |
1 | 0.00 |
| DOUBLE GRINDING MACHINE with led lighting |
mounted at the right handside of the workbench | 1 | 0.00 |
| BENCH COLUMN DRILL (with tools & accessories) |
mounted at the left handside of the workbench drilling capacity diam - steel 35 mm table orientation: 360° table tilt: 45° machine size: L 665 x W 434 x H 1000 mm weight: 137 kg |
1 | 0.00 |
| DRILLING & MILLING MACHINE (with tools & accessories) |
reversible tapping system;drilling capacity 25 mm, milling capacity 25 mm; max. tapping capacity M12 max. face milling capacity 50 mm; longitudinal axis 460 mm; cross axis 145 mm; motor "Brushless" 230 V / 1 kW |
1 | 0.00 |
| METAL DRY CUTTING SAW | Dry cuts stainless steel, ferrous and non-ferrous metal, plastic and aluminum tubes, profiles round shape: max diam 200 mm |
1 | 0.00 |
| drawer 5 DRILLING VICE |
max. opening 160 mm to be adapted on the bench column drill with T shape bolts, washers & nuts |
1 | 0.00 |
| DRILLING & MILLING VICE | 1 | 0.00 | |
| METRIC DRILLS SET | from 1 to 24 mm by 0,5 mm | 1 | 0.00 |
| MILLS SET | 1 | 0.00 | |
| BORINGS SET | 1 | 0.00 | |
| BROKEN BOLTS & SCREWS EXTRACTORS SET |
1 | 0.00 | |
| SET OF TAPS AND DIES | box dimentions 44 x 33 x 5,8 cm 35 dies M2-M18, 35 taps M2-M18 + accessories |
1 | 0.00 |
Detail pictures
The HOWO 4x4 workshop and lubrication equipment platform is made of a subframe with crossmembers and covered by checkered steel plates 3/5 mm thickness.A rigid steel frame supports the metal top and the drop sides. Drop sides and upper flaps are made of aluminum profiles and are on three sides, giving accessibility to operate and handle the lubrication equipment and workshop facilities.
| DESCRIPTION | SPECIFICATIONS | QTY | PRICE |
| WORKBENCH ON WHEELS dim.780x520x970mm - 80kg |
workbentch with 9 drawers on wheels wooden plate adjusted on top drawers inner dim. Width 569x Depth 421 Height 60/130 8 drawers 8x60 1 drawer 1x130 |
1 | 0.00 |
| 360° ROTATING VICE TO BE MOUNTED ON THE WORKBENCH |
distance between bits: 150 mm | 1 | 0.00 |
| drawer 1 (left side) 8 SCREW DRIVERS MODULE |
3X75; 5x100; 4x100; 5x125; 5x150; 8x175 1x100; 2x125 |
1 | 0.00 |
| drawer 1 (middle) 4 PLIERS MODULE |
1 universal pliers; 1 cutting pliers; 1 long nose pliers; 1 curved nose pliers; |
1 | 0.00 |
| drawer 1 (right side) 2 SPECIAL PLIERS MODULE |
1 loccking pliers 1 adjustable pliers |
1 | 0.00 |
| drawer 2 (left side) 4 SNAP RING PLIERS MODULE |
1 interior circlips pliers (right - nose) 1 interior circlips pliers (90°) 1 external circlips pliers (right - nose) 1 external circlips pliers (90°) |
1 | 0.00 |
| drawer 2 (middle) OIL CHANGE & OIL FILTER WRENCH MODULE |
1 fast recovery wrench; 13 diffrent tips |
1 | 0.00 |
| drawer 2 (right side) STRIKING TOOLS MODULE |
1 hammer; 1 mallet with interchangeable plastic head 1 puncher; 1 throttle; 3 pin punches (4-5-6 mm) |
1 | 0.00 |
| drawer 3 (left side) ALLEN WRENCHES MODULE |
Allen wrenches module from 3 to 19 mm; socket wrenches; accessories |
1 | 0.00 |
| drawer 3 (middle) "T" SHAPE ALLEN WRENCHES WITH HANDLE MODULE |
7 male Allen wrenches "T" shape with handle & spherical heads |
1 | 0.00 |
| drawer 3 (right side) SOCKETS MODULE |
sockets from 10 to 32 mm + accessories 21 pieces |
1 | 0.00 |
| drawer 4 (middle) COMBINATION WRENCHES MODULE |
16 combination wrenches from 6 to 22 mm; & 24 mm |
1 | 0.00 |
| drawer 4 (right side) LARGE COMBINATION WRENCHES MODULE |
4 combination wrenches from 27 to 30 mm; & 32 mm |
1 | 0.00 |
| drawer 5 3 ADJUSTABLE WRENCHES 13, 30 & 62 mm |
Adjustable wrenches with scales, chrome-plated • Movable jaw opening right-hand rotation of pin • Head angled at 22.5 degrees, with mm and inch scale |
3 | 0.00 |
| drawer 5 ADJUSTABLE WRENCH |
Stillson type (overall length 450 mm) opening up to 60 mm |
1 | 0.00 |
| drawer 5 ADJUSTABLE WRENCH |
Swedish type (overall length 450 mm) opening up to 55 mm |
1 | 0.00 |
| drawer 5 EFFORT LEVERS |
set of 3 pairs (max length 500 mm) 6 pieces in total |
6 | 0.00 |
| drawer 5 STRIPPING PLIERS (curved at 2 sides) |
curved at 2 sides L: 495 mm |
1 | 0.00 |
| drawer 5 STRIPPING PLIERS (curved at 1 side) |
curved at 1 side L: 450 mm |
1 | 0.00 |
| drawer 5 CLIC-TYPE TORQUE WRENCH |
Click-type torque wrenches with reversible ratchets for right-hand tightening torque accuracy: ±4% 40÷200 Nm L= 440 mm |
1 | 0.00 |
| drawer 6 SHEET METAL SCROLL SHEARS |
cutting capacity: 12/10 L: 230 mm blades lenght: 30 mm |
1 | 0.00 |
| drawer 6 CISSORS |
1 | 0.00 | |
| drawer 6 CUTTER WITH ADJUSTABLE LARGE BLADE |
dubble sides blades dubbel shapes blades blades dispenser |
1 | 0.00 |
| drawer 6 CUTTER WITH ADJUSTABLE NARROW BLADE |
single side blades blades dispenser |
1 | 0.00 |
| drawer 6 PIPE CUTTER |
dimensions: 130 x 34 mm length: mini 255 mm; maxi 310 mm capacity: from 10 to 42 mm or 1/8" to 1" |
1 | 0.00 |
| drawer 7 CUTTING + FILES + METER + ETC TOOLS |
1 | 0.00 | |
| DIGITAL UNIVERSAL MULTIMETER + ACCESSORIES |
Tension DC: 0-1000V; AC Tension: 0-750V; DC Courant: 0-20; AC Courant : 0-20 • Résistance: 0-20; Capacité: 0-20uF • Température: -40 à 1000; Fréquence: 20 kHz • Transistors hFE mesure; Testeur de continuité acoustique; LED de test |
1 | 0.00 |
| VOLTAGE TESTER | Alligator clip connects to ground. Long flexible test lead. |
1 | 0.00 |
| VOLTAGE TESTER | measures the flow of electrical current voltage tester rated from 6 to 690 volts. |
1 | 0.00 |
| METRIC DIGITAL SLIDES | 1 | 0.00 | |
| PRESS SET | 100 mm; 200 mm & 300 mm pair | 6 | 0.00 |
| drawer 9 PULLER SET (external) |
1 | 0.00 | |
| drawer 9 PULLER SET (internal) |
1 | 0.00 | |
| drawer 9 BEARINGS PULLER SET |
this hydraulic puller is ideal for maintenance of vehicles, mechanical installation by eliminating pulley, bearings, gears and others, includes: 1 x beam, 1 x central adapter, 6 x 1 x 10-ton hydraulic jack, 1 x extension Rod Ø 120-150 mm separator bearing |
1 | 0.00 |
|
DESCRIPTION |
SPECIFICATIONS | QTY | PRICE |
| N° 2 METAL CABINET HARDWARE SETS STORE |
metal cabinet (7/10 mm steel sheet) with hinged doors; 1 lock + key overall: W 800 x D 400 x H 1800 mm useful/ W 790 x D 380 x H 1640 mm weigth: 98 kg 4 adjustable tablets (45 kg per tablet) |
1 | 0.00 |
| CORDLESS DRILL WITH 2 BATTERIES & LOADER |
18V Cordless drill LED lamp integrated to illuminate the work area 10 MM self-locking chuck variable speed to drill & to screw |
1 | 0.00 |
| ELICTRICAL GRINDER | power supply: mains 230V - power: 400W degree of inclination: 45 / 90 °; laser guide variable speed: 900 to 1400 RPM belt width: 130mm - depth of cut: 44mm [45 °], 63mm [90 °] - rubberized handle delivered with 14 accessories. |
1 | 0.00 |
| 2 GRINDERS | idle speed max. 11000 & 6600 RPM disc diameter 125 mm & 230 mm hole diameter 22.23 mm Dimensions (L x w x h) 266 x 138 x 103 mm net & 473 x 249 x 140 mm; weight 1.8 kg & 5,8 kg |
1 | 0.00 |
| MINI MULTI PURPOSE TOOL | multi-purpose tool for works such as cutting and grinding, in all kinds of materials wist nozzle, not necessary touse a key to tighten and loosen the clamp accessory equiped with Li-ion 10.8 V battery & charger (1 hour) |
1 | 0.00 |
| WELDING SET | All soldering iron kit; contains a soldering gun power 1000W light instant heat, a fine tip 300W soldering iron. a tool for desoldering aluminum, soldering iron, wire welding machine and mould, magnifier etc, |
1 | 0.00 |
| TIG PORTABLE WELDING TOOL | for quality alloy steel, non-alloy, stainless, copper, starting hot and arc force are adjustable better directed arc for best results when scanned-pass welding Use on regulated generators weight: 10kg ; L 418 x w 188 x h 208 (mm) |
1 | 0.00 |
| OXY-ACETYLENE WELDING KIT | for welding up to 6 mm thick steel and cutting 12,5 mm thick steel; torch handle; 4,5 m x 6 mm twin hose; oxygen & acetylene regulators; welding tips 0/2/4; tip cleaner; rosebud tip; spark lighter; coupling nut; spanner; goggles |
1 | 0.00 |
| GASKETS CUTTERS SET | diam.from 2 to 60 mm with circular cutter diam.420 mm dim.380 x 330 x 55 mm weight : 5.4 kg |
1 | 0.00 |
| SET OF 2 SUPPORTS CAPACITY : 15 T EACH |
capacity: 15 tons max height 680 mm (per unit) mini height: 470 mm dimensions of the package: 380 x 380 x 490 mm net weight: 27 kg gross weight: 29 kg |
1 | 0.00 |
| ROLLING JACK 30/15 T | 430 X 150 mm 30 kg |
1 | 0.00 |
| 15 T HYDRAULIC JACK SET (2) | capacity 15 Tonnes min height 230 mm max lifting height 250 mm extension height 80 mm base dim 133x136 mm weight 8.4 kg |
2 | 0.00 |
| TRUCK AIR IMPACT WRENCH SET | 1 | 0.00 | |
| WET & DRY VACUUM CLEANER | 1300 W max 35 Ltr dimensions (LxWxH) 520 x 380 x 580 mm weight: 11,5 kg |
1 | 0.00 |
| GREASER KIT | Selection of delivery tubes and hoses, with couplers for all common types of grease nipple. Case 310 x 110 x 55 mm. |
1 | 0.00 |
| FLEXIBLE FUNNEL |
1 |
0.00 |
HOWO all wheel Drive 4x4 Mobile Workshop Truck : it's used for truck maintenance service with necessory equipment
installed inside truck van. The equipments can be customized according to customer's need.
2. Main parts of HOWO 4x4 Mobile Workshop Truck: diesel generator, Arc/Gas Welding & Cutting Machine, air compressor, Lube filling System,
Washing Machine, Tire Rack, Tire vulcanizing machine, Power distribution cabinet,T ool Cabinet...
3. The truck rear can be installed with 2tons, 3tons, 6tons folding crane.
