Products Description
Septic tank delivery truck is a specialized vehicle used to transport and deliver septic tanks to various locations. These trucks are designed to safely transport the tanks and efficiently deliver them to sites where they are needed.
The septic tank delivery trucks are equipped with large trailers that are specifically designed to carry septic tanks of different sizes and capacities. The trailers are constructed with durable materials to ensure they can withstand the weight of the tanks and prevent any damage during transportation.
The tanks are securely loaded onto the trailers using specialized equipment, such as cranes or hydraulic lifts, which ensure a safe and efficient loading process. The tanks are then strapped or secured to the trailers to prevent any movement during transit.
The howo septic delivery trucks are also equipped with advanced navigation systems and GPS technology to ensure that the tanks are delivered to the correct locations. This technology helps the drivers plan the most efficient routes and avoid traffic congestion, ultimately saving time and ensuring timely deliveries.
The septic tank delivery trucks also have safety features, such as anti-lock braking systems and rearview cameras, to provide the drivers with better visibility and control over the vehicle. This helps to prevent accidents and ensure the safety of both the drivers and other road users.
Key Features
----►WD615.69, Euro 2 diesel engine
----►HW1971 patented transmission, extremely reliable.
----►HC16 dirving axle, with hub reduction.
----►Heavy duty suspension, for africa road.
----►400L fuel tank, suitable for long drive.
Technical Specification
| HOWO 20cbm Vacuum Suction Jetting Truck PictureTechnical date | |||
| General | Descriptions | Specifications and types | |
| Truck Brand | CS TRUCKS | ||
| Chassis Brand | HOWO | ||
| Approx. Dimension | 10150*2550*3800(mm) | ||
| GVW./Curb Wt. | 25000(Kg)/ 17435Kg | ||
| Cab | Cab Capacity | 2 persons' seat | |
| Air Conditioner | Air Conditioner | ||
| Chassis | Drive Type | 6*4,Left hand drive | |
| Fuel Type | Diesel | ||
| Engine Make & Model | Weichai | ||
| Model | WP12.400E201 | ||
| Power | 400hp | ||
| Emission Standard | EURO 2 | ||
| Brake | Air Brake | ||
| Wheelbase/No.of axle | 4625+1350mm / 3 | ||
| Tyre Specfication | 12.00R20 | ||
| Tyre Number | 10 tyres and 1 spare tyre | ||
| Max Speed | 90 km/h | ||
| Paint | Automative metallic paint | ||
| Tank | Capacity | Vacuum Tanker:20CBM | |
| Material | Carbon Steel | ||
| Thickness | 8mm | ||
| Vacuum Pump | Brand | morop | |
| Produce country | Italy | ||
| Model | 110 | ||
| Flow | 984M3/H | ||
| Vacuum Pipe | Length | 8m | |
| Jetting pump | Brand | Pinfu | |
| Flow | 330L | ||
| High Presssure | 18Mpa | ||
| Reel | Rotation | 180 degree | |
| Control system | Hydraulic | ||
| Type | Wash system | ||
| Length | 60meter | ||
| Nozzle | 10pcs | ||
| The interior of the sewage tank is covered with stainless steel plates, the bottom of the anti-corrosion tank is convenient for unloading, and there is a ladder inside the tank | |||
| Double roof design of the left and right oil cylinders of the tank (with buffer support rods), the lifting and lowering of the tank is more reliable, and the vehicle stability is strong | |||
| The water inlet of the water tank is a ball valve type fire hydrant (convenient to switch and durable), with a fire protection interface, with a thick liquid level tube, and with a pagoda type hand washing method valve | |||
| With water and sewage intercommunication function (DN100 bold connecting pipe) | |||
| An anti-overflow valve is installed on the top of the sewage irrigation, and a three-jaw tank mouth is installed on the bottom of the sewage irrigation (easy to clear the tank) | |||
| Both sides are tiled with patterned plate pipe platform, galvanized protective net, patterned anti-slip guardrail, beautiful and durable | |||
| There is a ladder on the side of the tank, and a checkered plate flat belt on the top of the tank, with guardrails | |||
| The operating system is neatly arranged in the operation box, and there are operating instructions and precautions (to prevent misuse) | |||
| Both the high-pressure three-way valve and the sewage suction four-way valve are equipped with shock-resistant pressure gauges with a diameter of 100 mm, which can resist the vibration of the working environment and reduce the pulsation of the medium pressure, and accurately display the actual pressure | |||
| Standard configuration is a tool box, a 100 sewage suction port, 2 100 sewage discharge ports, a 150 sewage discharge port (with ball valve booster rod) and a 600 sewage discharge port at the end (hydraulic opening, with locking device) | |||
Cesspool truck detail
Customzied tanker colour
Classic front cabin face
12.00R20 tyre
Discharge outlet
Stainless steel Opertion valve
Hydraulic lifting cylinder
Implementation in city drainage
The Jurop PN106 vacuum pump is a high-performance model specifically designed for heavy-duty applications. It offers a range of advanced features and specifications that make it a reliable and efficient choice for various industries
Howo sewage suction truck is a tool specially used to clean urban sewers. It mainly uses suction to remove dirt and blockages in the sewer to ensure that the sewer is smooth and hygienic.
1, the sewage suction truck needs to go to the sewage treatment plant and the maximum depth of the sewer to prepare for the cleaning work. Operators must wear protective clothing and masks to ensure their own safety.
2, the sewage suction truck inserts the sewage suction pipe into the sewer, and uses strong negative pressure suction to suck the dirt deposited in the pipe into the storage tank. Sewage suction trucks are usually equipped with high-efficiency filtration systems that can filter out smaller particulate matter and maintain the suction effect. During the cleanup process, pay special attention to difficult-to-treat dirt such as grease, twigs, or other solid materials.
Jurop vacuum pump
Jurop vacuum pump
Jurop vacuum pump
Factory production
