The production process of Isuzu folding crane cargo truck strictly follows international standards and quality control systems. From the selection of the chassis to the manufacturing of the boom, every link is carefully designed and subject to strict quality control. Use advanced machining equipment and welding technology to ensure that every component is accurate. Especially in the manufacturing process of the boom, high-strength, lightweight materials are used to ensure the rigidity and strength of the boom, while reducing the overall weight and improving fuel economy.
In terms of lifting capacity, this Isuzu cargo truck with folding crane has a maximum lifting height of 9.5 meters, a maximum lifting weight of 4,000 kilograms, a maximum lifting moment of 6 tons and a maximum working radius of 7.5 meters, which can meet most lifting operations. needs. Isuzu cargo truck with folding crane adopts a folding boom design, which is not only compact in structure, but also flexible in operation, and can complete efficient lifting operations in a limited space.
In terms of safety and comfort, Isuzu cargo truck with folding crane also performs well. It is equipped with a complete electrical system, including tail, signal, reversing, brand lighting and side marker lights, etc., which improves driving safety at night and in bad weather. At the same time, reflective tapes are affixed to both sides and rear of the Isuzu folding crane cargo truck, further enhancing the visibility of driving at night. In addition, the design of the cab also fully considers the driver's comfort, providing a spacious interior space and comfortable seats, allowing the driver to remain comfortable and focused even during long hours of work.
Specification Data
|
TECHNICAL SPECIFICATION |
||
|
Main specification |
Chassis brand |
Chassis brand ISUZU |
|
Overall dimension(L*W*H) |
8600*2450*2850mm |
|
|
Kerb weight |
3,400kg |
|
|
Gross weight |
10,550kg |
|
|
Drive modle |
4*2, left hand drive |
|
|
Wheel Base |
4475 mm |
|
|
Front Axle loading capacity |
4 tons |
|
|
Rear Axle loading capacity |
7 tons |
|
|
Transmission |
MLD 6 speed forward 1 reverse. |
|
|
Maximum speed |
95km/h |
|
|
Tyre size |
235/75R17.5, with one spare tyre |
|
|
Engine horse power |
190hp |
|
|
Engine emission standard |
EURO 6 |
|
|
CRANE PARAMETERS |
||
|
Crane model |
Chinese Famous brand |
|
|
Max Lifting Height(m) |
9.5 |
|
|
Max lifting capacity(kg) |
4000 |
|
|
Max lifting moment(T.M) |
6 |
|
|
Max working radius(m) |
7.5 |
|
|
Type of Crane |
Floding boom crane |
|
|
Recommend Powe(kw) |
25 |
|
|
Rated Oil Flow of Hydraulic System(L/min) |
38 |
|
|
Rated Pressure of Hydraulic System(MPa) |
23 |
|
|
Oil Tank Capacit(L) |
200 |
|
|
Rotation Angle |
360° all rotation |
|
|
Crane Weight(kg) |
3000 |
|
|
Installation Space(mm) |
1530 |
|
|
CARGO BOX |
||
|
Dimension |
6000*2350*600mm |
|
|
Rear bumper |
Carbon steel |
|
|
Side Under Run |
Carbon steel |
|
|
Mud guard / Mud Flap |
with Mudguard and rubber mud flap |
|
|
Spare Wheel Bracket |
1piece |
|
|
Light |
Electrical system in accordance to Chinese standard, complete with Chinese's light for tail, signal, reverse, nameplate light and, and side marker lights at both sides of truck, complete with reflective tape at two sides and rear of the truck. |
|
|
Painting |
According to customer wish |
|
Isuzu folding crane cargo truck
Performance features
1. Efficiency: Equipped with a powerful engine and advanced transmission system, the Isuzu NPR folding crane cargo truck has excellent acceleration and climbing capabilities, ensuring efficient operation under various complex road conditions.
2. Stability: The solid chassis and excellent suspension system ensure the stability of the Isuzu NPR folding crane cargo truck during the lifting process, and it can remain stable even when moving at high speed or lifting heavy objects.
3. Flexibility: The folding crane design allows the boom to be flexibly operated in a limited space, whether it is a narrow street in a city or a complex construction site, it can easily handle it.
4. Safety: In addition to the complete electrical system and reflective tapes, the Isuzu NPR folding crane cargo truck is also equipped with active safety technologies such as ABS anti-lock braking system and EBD electronic brake force distribution system, which greatly improves driving safety.
Wide range of uses
Isuzu NPR folding crane cargo truck is widely used in various hoisting and transportation operations due to its excellent performance and stable quality.
1. Construction industry: Whether it is urban high-rise buildings or rural infrastructure construction, a large amount of lifting operations are required. Isuzu NPR folding crane cargo truck has become a powerful assistant in the construction industry with its high efficiency and stability.
2. Logistics industry: In the logistics industry, goods often need to be moved from one place to another quickly and safely. Isuzu NPR folding crane cargo truck ensures the safety of cargo during transshipment with its powerful lifting capacity and stable performance.
3. Rescue industry: At the scene of natural disasters or accidents, rapid and effective rescue is often required. The Isuzu NPR folding crane cargo truck can quickly arrive at the scene and use its lifting capabilities to rescue trapped vehicles or people.
4. Municipal maintenance: In daily maintenance of the city, such as street lamp replacement, billboard installation, etc., hoisting equipment is also required. The Isuzu NPR folding crane cargo truck provides strong support for municipal maintenance with its flexible operation and stable performance.
