Products Description
The folding arm truck-mounted crane is a kind of mechanical equipment that integrates lifting and transportation. It has the characteristics of retractable folding arm. It mainly consists of chassis, lifting mechanism, folding arm and control system. First of all, the beiben 2638 chassis of the knuckle arm truck crane is the foundation of the entire equipment, responsible for carrying the weight of the lifting mechanism and the knuckle arm, while providing a stable driving and working platform.
The NG80B beiben chassis usually uses a high-power engine and a powerful transmission system, giving it a high load capacity and excellent off-road capabilities, and can adapt to various terrains and working conditions.
the lifting mechanism is the core component of the knuckle arm truck-mounted crane and is responsible for lifting and hoisting operations. The lifting mechanism adopts electro-hydraulic proportional control and hydraulic system, which can automatically control according to the lifting quality while ensuring lifting efficiency. At the same time, the lifting mechanism is also equipped with hooks and balance damping devices to ensure stability and safety during lifting.
Key Features
----► NG80B cabin, mercedes benz technology.
----► Full welded steel cargo box, Q345 carbon steel.
----►XCMG crane, UNIC,Palfinger crane avaiable.
----►12 months long guarantee , for africa country.
----►Easy operation and convenient maintenance
2634 beiben crane truck specification
The folding arm is a special feature of the folding arm truck-mounted crane, which can be folded and retracted to adapt to different lifting distances and operating environments. Through the control of the hydraulic system, the folding arm can expand and contract at different angles and lengths, thereby achieving flexible adjustment and precise positioning of the lifting mechanism. This adjustable folding arm design greatly improves the operating range and efficiency of the folding arm truck crane.
| TECHNICAL SPECIFICATION | |||||
| Main specification | Chassis brand | North Benz | |||
| Chassis model | 2634PZ | ||||
| Overall dimension(L*W*H) | 10800*2540*3055mm | ||||
| Axle No. | 2 | ||||
| GVW | 25000kg | ||||
| Drive modle | 6x4, left hand drive | ||||
| Wheel Base | 5050+1450mm | ||||
| Front/Rear Wheel distance | 2065/1855mm | ||||
| Front Axle | 7.5ton | ||||
| Rear Alex | 13ton*2 | ||||
| Tyre size | 12R22.5 18R, with one spare tyre | ||||
| Tyre number | 10+1 nos | ||||
| Engine | Fuel/Engine type: | WP10.340E32 | |||
| Engine horse power | 340hp | ||||
| Engine emission standard | EURO 3 | ||||
| Upper Body | |||||
| Crane | Type | folding arm | |||
| Max lifting capacity(T) | 10 | ||||
| Max torque(T.M) | 25 | ||||
| Hook part line ratio | 6 | ||||
| Max operating range(M) | 13.9 | ||||
| Max lifting height(M) | 15.5 | ||||
| Boom number | 4 | ||||
| Control position | Ø Ground control | ||||
| Ø Optional high seat control | |||||
| Cargo box | Cargo box Dimension | 8000*2350*1500MM | |||
| Thicness | bottom: 3mm, side: 1.5mm | ||||
| Material | Carbon steel | ||||
Beiben crane truck detail
The folding arm truck-mounted crane is a common construction site lifting equipment and can be widely used in construction sites, docks, metallurgy, chemical industry and other industries. It has a folding arm form for easy operation in small spaces and has large lifting capacity and flexibility.
1, in construction sites, knuckle-arm truck-mounted cranes are mainly used to transport and install building materials, such as steel structures, concrete components, etc. Its flexible folding arm can easily enter small construction site spaces and accurately lift heavy objects to designated locations. At the same time, the knuckle arm truck-mounted crane has a large lifting capacity and can handle building materials of various weights, improving construction efficiency and safety on the construction site.
2, in terminal operations, knuckle-arm truck-mounted cranes are mainly used for loading and unloading containers and cargo. It can complete hoisting operations by telescopic and rotating the boom, effectively improving the efficiency of terminal operations. The folding arm truck-mounted crane can also be equipped with a remote control system, so the operator can operate in a safe area to reduce the risk of personal injury.
3, knuckle arm truck-mounted cranes can also be used in the metallurgical and chemical industries. In the metallurgical industry, it can be used to lift and transport heavy materials such as metals, ores and smelting products. In the chemical industry, folding arm truck-mounted cranes can be used to transport chemical raw materials and finished products to meet the needs of different processes.
The application of knuckle arm truck-mounted cranes also needs to take into account the topography and environmental factors of the construction site. For example, for construction sites with rugged terrain, you can choose a folding arm truck crane with off-road capabilities to ensure the stability and safety of the equipment. In addition, you also need to pay attention to the maintenance and upkeep of the equipment, and promptly check various parameters and components of the equipment to ensure its normal operation and safe use.
The knuckle arm truck crane is a kind of lifting equipment used to carry and lift heavy objects. It consists of a fixed body and a movable folding arm. The following is the working principle of the folding arm truck mounted crane:
1. Body stability: The body of the folding arm truck crane is connected to the wheels through the chassis to ensure the stability and balance of the equipment during work. The body is equipped with a hydraulic system for driving the boom and other operations.
2. Folding arm lifting: The folding arm can rise and fall along the guide rails on the body. This lifting action is driven by a hydraulic cylinder or an electric motor. The folding arm can be adjusted and locked according to the work requirements.
3. Rotating platform: The rotating platform on the body can rotate 360°, allowing the folding arm to move in any direction. The rotating platform is hydraulically or electrically driven, allowing the folding arm to flexibly respond to the working environment.
4. Hook operation: The hook is installed at the end of the folding arm and is used for hanging and lifting heavy objects. Hydraulic cylinders or electric motors provide the lifting and lowering movements of the hook, allowing heavy loads to be operated at different heights.
5. Control system: The folding arm truck-mounted crane is equipped with a control system. The operator can control the lifting, rotation and hook operation of the boom through the controller or remote control. The control system also monitors the status and load of the boom.
