Isuzu Light 3CBM Dump Truck
video
Isuzu Light 3CBM Dump Truck

Isuzu Light 3CBM Dump Truck

Isuzu NKR 3CBM dump truck
Isuzu light-duty dump truck is a reliable model equipped with Weichai engine with 120 horsepower, suitable for heavy-duty transportation. Isuzu Heavy-duty dump truck uses water cooling, turbocharging and intercooling technology, and the engine adopts a 4-cylinder in-line design to provide efficient fuel injection. The cab is made of steel and features central locking, electrically controlled windows, adjustable driver and front passenger seats, stereo radio cassette player, seat belts, horn, air conditioning, rear view mirrors and ABS.

Model: CSC5040ZX
Capacity: 3 Tons
Drive: 4×2
Engine power: 120 HP
Engine type: 4KH1CN6LB
Send Inquiry
Description

Isuzu mini tipper lorry



Isuzu dump truck for sale

Isuzu mini tipper lorry is an important means of transport with automatic dumping and flexible operation. It has a wide range of applications in short-distance cargo transportation and construction site construction, and is commonly found in construction sites, mines, ports and urban logistics. It can transport a variety of materials such as earth, sand, stone, and construction waste, among others. Due to its small and flexible characteristics, the small dump truck can also operate freely in a narrow construction environment, which improves the construction efficiency.

Isuzu 100P light dump truck

The Isuzu light dump truck usually consists of an Isuzu 100P mini chassis and a small cargo box. The front of the vehicle is the part of the cab and the engine, which is responsible for controlling the driving of the vehicle and the working environment of the driver. The cargo box is the part used to load the goods, and different sizes and capacities can be selected according to the need. The chassis is the supporting structure of the vehicle, including the wheels, steering system and suspension system, which ensures the stability and safety of the vehicle.

Isuzu NKR light dump truck

The Isuzu light dump truck is a means of transportation that is commonly used for short-distance transportation and material transportation at construction sites, commonly found in construction sites, mines, ports, and urban logistics. It can transport a variety of materials such as earth, sand, stone, and construction waste, among others. Its main feature is that the automatic dumping function is realized through the hydraulic system, which can easily dump the goods to the destination and improve the work efficiency. At the same time, Isuzu's cab is usually equipped with air conditioning, audio and comfortable seats, which provides a good working environment and driving experience for the driver.


Products Description


Isuzu light dump truck



Isuzu Dump truck basic

Made

POWERSTAR

Series

ISUZU

Driving Type

Right/Left hand drive 4x2

Isuzu Dump Engine

Isuzu Dump Engine Model

ISUZU 4KH1

Engine Type

4-cylinder in-line with water cooling,turbo-charging and intercooling,4-stroke direct injection diesel engine

Power

98hp

Displacement

2.77L

Max speed

95 Km/h

Type of fuel

Diesel

Emission Standard

Euro 5

Isuzu Dump Transmission

Model

Isuzu MSB

speeds

5 speeds

Isuzu Dump Axle

Front Axle

2.5T

Rear Axle

4.5T

Isuzu Dump Fuel tank

Capacity

80L capacity with locking fuel cap

Isuzu dump Tyre

Radial Tyre

700R16

Isuzu Dump Driver's Cab

Mini Cab

Single cabin, full steel materials, central locking function, electrical controlled window, adjustable driver's seat and co-driver's seat, stereo radio cassette recorder, safety belts, air horn, air conditioner, rear view mirrors, ABS.

Isuzu Dump Dimensions

Wheel base

3360mm

Overall dimensions

5500*1980*2200 mm

Dimension of the rear dump body

2800*2300*1500 mm

Isuzu Dump Performance

Loading Capacity

3-4 tons

Body Material

High performance carbon

Plate Thickness

Front/Side are 3mm

Rear/Side are 4mm

Control System

Hydraulic

Hydraulic Lifting

Middle lifting device

Discharging System

Tipping 45 degree

Lifting Time

20 s

Lowering Time

15 s

Tailgate

Auto release

Drop side

Detachable

Painting

Two primers,and one final paint coating

Color & Logo

According to wish

Factory Standard

"U" shape Sub Frame, Hydraulic system, Ejector panel, Safety protection, Rotating Lamp, Working Lamp, Hand holds, Mudguards and rubber flaps...

Documents

English operation manual, Spare parts list, and all necessary export docs.

Optional equipment

1, Dust bin lifting system (with any option)

2, Rear vision camera

3, Italy imported multi-way valve

4, Optional stainless steel waste water tank



The benefits of using Dropside body for Isuzu Mini Dump Truck are as follows:

Isuzu small tipper trucks
Isuzu tipper truck for sale
Isuzu 3CBM dump truck for sale
Isuzu NKR light dump truck

1.Convenient unloading: One or more sides of the Dropside box can be opened or removed, making unloading more convenient and efficient. The cargo can be pushed or lifted directly from the side without the use of lifting equipment or other additional loading and unloading tools.

2.High flexibility: The Dropside box can be opened one by one or all side panels as needed, making loading and unloading items more flexible. This is particularly important for goods of different sizes or shapes, as they can be adjusted to specific needs.

3.Improve loading and unloading efficiency: Due to the open-side design of the Dropside box, goods can be put in or lifted out directly from the side, saving loading and unloading time. This is very beneficial for scenarios that require frequent loading and unloading of goods (such as construction sites, logistics distribution, etc.).

4.Convenient for transporting over-long cargo: If there is a need to transport cargo that exceeds the length of the vehicle (such as pipes, lumber, etc.), the Dropside box can be opened on multiple sides to extend the cargo out of the vehicle, providing greater transportation space and convenience.

5.Increased work safety: The side panels of the Dropside box can provide additional safety support to prevent the cargo from being damaged due to tilting, sliding or external impact during transportation. This is very important for the protection of the cargo and the safety of the driver and those around them.
