Products Description
Isuzu rear loader garbage truck is a type of waste collection vehicle that is designed to collect and transport garbage from residential and commercial areas. These rear loading garbage trucks are equipped with a rear-mounted hydraulic compactor that can compress the collected waste to maximize the truck's carrying capacity.
The rear loader garbage truck is a common sight in urban and suburban areas, where it plays a crucial role in keeping the streets clean and free from waste. These trucks are typically operated by municipal waste management departments or private waste collection companies.
The operation of a rear loader garbage truck is relatively straightforward. The vehicle is driven to the designated collection point, where the crew uses a hydraulic lift to raise and empty individual waste containers into the truck's hopper. Once the hopper is full, the hydraulically powered compactor is activated to compress the waste, allowing the truck to carry a larger volume of garbage.
Key Features
----► Isuzu 100P truck chassis, classis japan cabin.
----► High strength Q550 steel, 30% stronger than others.
----► Adapt to africa tough road conditions.
----► Super PLC control system, Germany technology
----► ITALY valve system, full copper high pressure pipe.
Technical Specification
| Mian Technology Parameter | |
| Model Name | Isuzu 100p garbage compactor truck |
| Driving Type | 4×2,left hand drive |
| Color | White,yellow,box can choose |
| Weights | |
| Rated payload weight(kg) | 4000 |
| Curb weight(kg) | approx.4550 |
| Dimensions | |
| Wheelbase(mm) | 3360(also can choose 3360mm wheelbase) |
| Overall Dimension(mm) | 6460×1880×2600 |
| Box dimension | 4 m3 |
| Max speed(km/h) | 98 |
| Engine | |
| Engine model | 4JB1CN(98HP) OR EURO5 engine |
| Engine type | 4 stroke water-cooled,inter-cooling |
| No. of cylinders | straight-4 cylinders |
| Displacement(L) | 2.999L |
| Max. output (kw) | 72kw |
| Emissions standard | Euro 4 |
| Drive Line | |
| Transmission | MSB 5 speeds ,5 forwards,1 reverse gear,manual operation |
| Steering | Power steering |
| Brake | Oil brake with vacuum pump |
| Cab | |
| Air container | Have |
| Standard configuration | Sound,,parking sensors |
| Axle | |
| Front axle | 2.5tons |
| Rear axle | 4.8 tons |
| Tire specification | |
| Tire specification | 7.00-15 standard tire,6 tires+1 spare tire |
| 6m3 garbage compactor truck | |
| Box valume | 4m3 |
| Box material | Side 4mm,bottom 5mm |
| Sewage tanker | 200L |
| Fill volume | 1.2cbm |
| Loading time | 8-10S |
| The cycle time of the loading | 50-60S/per turn |
| Unloading model | Dump |
| Unloading time | 30-40S |
| Hydraulic system pressure | 16Mpa |
Truck detail
Why choose isuzu rear loade compactor?
Operate & produce
Customize your own truck
The multi-way valve of a compressed garbage truck is a key component for controlling the operation of the compressor. Correct operation can improve the working efficiency and safety of the vehicle. The following are the operating steps for the multi-way valve:
1. Preparation: Make sure the garbage truck has stopped and turned off. Wear work clothes, a hard hat, gloves and goggles.
2. Find the multi-way valve: The multi-way valve is usually located on the control panel near the cab. It is a black square box equipped with an operating handle.
3. Open the multi-way valve: Open the protective cover of the multi-way valve and ensure that the valve is closed.
4. Select the valve position according to your needs: Multi-way valves usually have multiple valves, each valve corresponding to a different function. Operate the corresponding valve as needed, such as lifting, dumping or compressing.
5. Control handle operation: Push the handle up or down as needed to open or close the corresponding valve.
6. Observe the compression situation: During the operation of the multi-way valve, closely observe the operation of the compression garbage truck. Make sure the compressor is working properly and there are no abnormal sounds or vibrations.
7. Close the multi-way valve: After completing the operation, return the handle of the multi-way valve to its original position and close the protective cover.
8. Check the vehicle status: After operating the multi-way valve, carefully check the overall status of the garbage truck to ensure there are no abnormalities.
