Rear load trash truck Isuzu KV100 has been at the forefront of excellence, innovation, and customer satisfaction in the Waste Industry for more than 100 years. CS trucks proudly manufactures a wide variety of garbage truck collection bodies including residential and commercial front loaders, rear loaders, split body rear loaders, and side loaders.
Technical Specification
-
CS Trucks created the Load Packer garbage truck in 2005, which revolutionized the sanitation business. It was the first garbage truck with genuine compacting capabilities. Because the trucks could condense the rubbish while travelling through the city, they could transport twice as much as previously. These trucks were able to handle bigger items and compressed them more effectively, allowing them to carry a 25% greater load.
We could supply from 6m3 to 20m3 compression garbage truck Isuzu, hooklift refuse truck, skip loader waste collecting truck. With FAW, DONGFENG, HOWO, SHACMAN and other brand chassis. Send us more about your request please, we'll recommend you the suitable model.
Vehicle Brand
CS TRUCKS
Chassis brand: ISUZU KV100
Vehicle Main Dimensions
Overall dimensions (L x W x H) mm
6350x2400x3500
Wheelbase (mm)
3815
Weight in KGS
Gross Weight
8000
Payload Weight
4 Tons
Front /Rear axles loading capacity
4000 / 5000
Cab
ISUZU 3D cab, with A/C and 2 seats, Forward control, all steel welded construction. Manual tilt, Mechanical suspension
Driving type
4x2 left hand drive, 6 wheels
Engine
Model
ISUZU 4KH1
Horse Power（HP)
120 HP
Emission standard
Euro V( 3L)
Gearbox
ISUZU MSB 5-shift transmission, Manual, 5-speed forward, 1 reverse gears
Fuel tank (L)
70
Tire
7.00R16 tire 6 pcs including one spare tire
Upper body
Body Capacity
6 cbm
Hopper Capacity
1.4 cbm
Body Material
Weather Resisting Steel
Sewage Tank
200L + 100L
Compressing Ration
≥ 1:3.4
Working zone Lighting
2 lamps
Dust Bin Lifter
2 bins 240L
Control
Siemens Automatic-PLC system
Optional 1100L,660L
Manual, semi-automatic, automatic
Loading Cycle Time
15 ～ 20 sec
Foot Stands
2 sets
Discharging Time
10 ～18 sec
Painting
Two primers, and one final paint coating
Discharging system
Horizontal ejection
Color and Logo
According to wish
Standard equipment
“U” shape Sub Frame, Hydraulic system, Ejector panel, Safety protection, Rotating Lamp, Working Lamp, Hand holds.
Documents
English operation manual, Spare parts list, and all necessary export docs.
-
Detail pictures
Sanitation engineers load the garbage truck Isuzu along local streets. Trash being placed into a hopper in the back of a rear-loader vehicle Isuzu. The compacting mechanism, which removes the rubbish from the hopper and deposits it into the truck’s body, is controlled by hydraulic cylinders. The more junk that is stuffed into the body, the more compressed it becomes. The trash does not fall out of the truck while it is full or moving since the compacting device is on the exterior of the body.
The driver transports the rubbish to the dump when the truck is full. The compacting panels are moved out of the way by hydraulic cylinders when the vehicle tilts up like a dump truck. After that, the rubbish is tossed out of the vehicle and the rear is hosed out.
