Isuzu GIGA police fire truck chassis
The Isuzu GIGA police department fire fighting truck also called Isuzu GIGA police fire truck chassis,Isuzu GIGA 420HP police fire tender chassis,Isuzu GIGA police fire engine chassis,is a high-performance chassis designed for the public safety field. It is made of high-strength materials and advanced processes, and has excellent structural strength and durability. The Isuzu GIGA police department fire fighting truck chassis is equipped with a powerful engine and an advanced drive system, providing strong power support and stable handling performance, ensuring rapid response and efficient operation in various complex environments and road conditions. At the same time, it is also highly customizable and expandable, and can be personalized according to different firefighting needs to meet the needs of various firefighting scenarios. The excellent performance and reliability of the GIGA chassis make it a powerful assistant in the firefighting field and play an important role in ensuring public safety.
Advantage
Isuzu GIGA police fire truck chassis, as a special vehicle chassis built for the public safety field, has won wide acclaim in the industry for its excellent performance and sophisticated craftsmanship. This chassis not only inherits the reliability and durability of the Isuzu brand, but also shows its unique design concept and manufacturing process in the details.
First of all, from the appearance, the GIGA police fire tender chassis has smooth lines, simple and elegant design, and shows a strong sense of power. Its body structure is sturdy and can withstand various impacts and vibrations in firefighting operations, ensuring stable and reliable operation in emergency situations.
In terms of chassis configuration, th Isuzu GIGA police fire tender chassis adopts advanced suspension system and drive technology. Its suspension system has been carefully adjusted to provide excellent handling and comfort, and can maintain the stability and safety of the vehicle even in complex road conditions. At the same time, its drive system adopts efficient transmission mechanism and advanced control technology to ensure that the vehicle can perform at its best under various working conditions.
In terms of firefighting operations, the Isuzu GIGA police fire fighting truck chassis has demonstrated its excellent performance. It is equipped with a powerful fire pump and fire extinguishing system, which can quickly and effectively carry out fire extinguishing operations. At the same time, it is also equipped with advanced communication equipment and command systems, which can grasp the fire scene in real time and provide accurate command and dispatch for firefighters.
In terms of safety, the chassis of the Isuzu GIGA police fire truck also performs well. It uses high-strength steel plates and advanced welding technology to make the body structure more sturdy and durable. At the same time, it is also equipped with advanced safety configurations such as ABS anti-lock braking system and ESP body stability system, which can provide effective protection for the driver in an emergency.
In addition, the chassis of the Isuzu GIGA 420HP police fire truck also focuses on environmental protection and energy saving. It uses advanced emission control technology and fuel economy optimization technology, so that the vehicle meets the performance requirements while also meeting the requirements of environmental protection and energy saving.
Products Description
|
Chassis Brand |
Isuzu |
|
|
Vehicle Dimensions and Parameters |
Overall Dimension(L x W x H) |
9100×2540×3750mm |
|
Wheelbase: |
5550mm |
|
|
Front/ Rear Wheel Distance: |
2065/1875mm |
|
|
Front/Rear Suspension |
1370/2180mm |
|
|
Weights and Capacities |
Curb Weight: |
9850kg |
|
GVW: |
22000kg |
|
|
Axle Loads: |
7000/14000kg (Two-Axis Group) |
|
|
Engine |
Engine Model: |
6WG1-TCG60 |
|
Max output: |
309Kw |
|
|
Displacement: |
15681ml |
|
|
Horsepower: |
420HP |
|
|
Exhaust Gas Treatment Technology： |
SCR |
|
|
Cabin |
Number of Seats: |
2 |
|
Cabin type |
Single row and standard roof 1 berth |
|
|
Chassis |
Drive Type: |
4x2,LHD |
|
Tires: |
7(Including Spare Tire) |
|
|
Tire Model |
295/80R22.5 |
|
|
|
Max Speed |
90Km/h |
|
Fuel tank |
Capacity |
600L |
|
Configurations |
1 |
Power Steering System |
|
2 |
Air Conditioning |
|
|
3 |
Central Lock |
|
|
4 |
Power Window |
|
|
5 |
ABS |
|
|
6 |
Driving Data Recorder |
|
|
7 |
Tubeless Tire |
|
|
8 |
Free Maintenance Battery |
|
|
9 |
Aluminum Alloy Gas Tank |
|
|
10 |
Air Suspension Cabin |
|
|
11 |
Air Suspension Seat |
|
|
12 |
Widened Bumper |
|
Isuzu GIGA police fire truck chassis plays a vital role in the Word, which is reflected in the following aspects:
Improving fire response speed:
● The strong power and excellent handling of the GIGA chassis enable fire trucks to respond to fire alarms quickly, especially in cities and complex terrains in the Philippines. Its high adaptability ensures that fire trucks can quickly reach the fire scene.
● The Philippines has diverse geographical environments and climatic conditions. The excellent performance of the GIGA chassis ensures that fire trucks can operate stably in various environments, providing strong guarantees for rapid rescue.
Enhancing firefighting efficiency:
● The GIGA chassis can carry large-capacity fire pumps and fire extinguishing systems, which is particularly important for the Philippines as the country often faces various fire challenges, including forest fires and urban fires.
● The chassis' efficient fire extinguishing system can quickly control the fire and reduce the harm of fire to people's lives and property, which is of great significance to protecting public safety in the Philippines.
Ensuring the safety of firefighters:
● The advanced safety configurations equipped with the GIGA chassis, such as ABS anti-lock braking system and ESP body stability system, can provide effective protection for firefighters in emergency situations and reduce the possibility of accidents.
● Under the harsh climate conditions of the Philippines, such as high temperature and heavy rain, the comfort and stability of the GIGA chassis can provide firefighters with a relatively safe and comfortable working environment and reduce their work pressure.
Promote the development of firefighting:
● The widespread use of the GIGA chassis in the Philippines has not only improved the country's firefighting equipment level, but also promoted the rapid development of the firefighting industry.
● By introducing advanced firefighting technology and equipment, the Philippines can better cope with various fire challenges and improve the overall fire safety level.
