Products Description
The combination sewer cleaner is a special vehicle that combines the functions of two special vehicles, a high-pressure jetting truck and a sewage suction truck. The working principle of the combined sewer cleaner vehicle is to suck the sewage from the sewer through the sewage suction pipe system, and then place the high-pressure pipe with the reel at a constant speed. When the high-pressure flushing pipe is working, the rotational force causes the high-pressure flushing pipe to enter the clogged sewer pipe that cannot be reached by manpower. Carry out high-pressure penetration operations to restore the smooth flow of sewer pipes.
This HOWO sewer jetter cleaning truck is mainly used for sewage discharge and dredging operations in urban and rural sewers; its main devices are sewage tanks and clean water tanks. The effective volume of the sewage tank is 8 cubic meters, and the medium that can be filled is liquid sewage with a density of 800 kg/cubic meter; the effective volume of the clean water tank is 4 cubic meters, and the medium that can be filled is water with a density of 1000 kg/cubic meter. The water tank and the sewage suction tank are two independent tanks. The clean water tank is used for cleaning function, and the sewage tank is used for sewage suction function.
Products technical Specifications
HOWO sewer jetting truck integrates high-pressure dredging, material suction, loading and unloading and transfer functions. It is mainly used for sludge suction, cleaning and transfer in urban underground pipe networks. It can dredge and clean urban pipelines through high-pressure water and clear out the contents of the pipelines, sludge and dirt attached to the pipe wall.
|
Item |
Main parameter |
|
|
Complete vehicle |
Vehicle name |
HOWO combination sewer cleaner truck |
|
Wheelbase |
4700 mm |
|
|
Gross weight |
18000 kg |
|
|
Overall dimensions |
8430×2530×3400 |
|
|
Engine |
Model |
WP10.290 |
|
Emission standard |
EURO 3 |
|
|
Power |
290 HP |
|
|
Displacement |
10 L |
|
|
Sludge tank |
Tank volume |
8 m3 |
|
High pressure dredging and flushing |
Water tank volume |
4 m3 |
|
Type of high pressure pump |
Plunger triplex pump |
|
|
Maximum working pressure bar |
230 |
|
|
Flow rate L / min |
325 |
|
|
Dredging Distance m |
≥120 |
|
|
Nozzle |
10 units |
|
|
Vacuum system |
Vacuum degree bar |
-0.97 |
|
Air flow m3/h |
1400~5700 |
|
|
Suction time |
≤4 min. |
|
|
Suction head |
≥20 m |
|
|
European type overhead disk suction arm |
The length of the suction pipe can be adjusted automatically according to the depth of the suction material, which can be operated remotely, rotated by 300 degrees, horizontally stretched, etc |
|
|
Reel |
The reel is fixed on the rear of the tank, with 60 meters high pressure pipe |
|
|
Operation |
Suction, pressure discharge, rear cover |
Remote control operation within 50m, including suction and other functions |
|
Emergency safety protection |
Install the emergency safety protection switch on the vehicle operation panel to ensure the safety of the vehicle and personnel in an emergency state |
|
|
Pressure discharge system |
Through the pressure drainage system, the waste water in the waste tank that does not need to be transported can be discharged back to the sewer pipeline on site, without the need for vehicles to go back and forth, so as to improve the operation efficiency |
|
|
Optional features |
Four stage sewage recycling system |
Sewage and water can be separated on site and filtered for high-pressure dredging, cleaning and reuse |
|
Sludge pressing and dewatering system |
The separated sludge can be pressed and dehydrated to further reduce the water content and volume of sludge and sewage and reduce waste discharge. |
|
|
Horizontal unloading system |
The discharging speed is faster and more thorough, and the dirt can be cleaned out without lifting the can body. |
|
|
Digital operating system |
The special 10 inch display, programmable controller and can bus control technology are used to digitally display various signal parameters of the whole vehicle, and realize the functions of automatic fault diagnosis, automatic alarm and automatic cut-off. |
|
Products Advantanges
1. Powerful suction, convenient and flexible
Equipped with industry-unique two-stage and three-stage centrifugal fans, it has large air volume, strong suction capacity, simple maintenance, and can suction both dry and wet materials. At the same time, it is equipped with a suction arm that can flexibly vary, rotate, and telescope, making the suction operation more convenient and efficient.
2. High pressure cleaning, powerful dredging
Use a high-flow high-pressure water pump with a maximum pressure of 20MPa and strong dredging and cleaning capabilities. Matching different types of nozzles, it can remove sediment in various pipelines and dirt attached to the pipe wall.
3. Intelligent control, convenient and friendly
The entire vehicle is intelligently controlled and dynamically detects and monitors the operating parameters of key systems such as the suction system, hydraulic system, chassis, etc. Some models are equipped with LCD screens, so the vehicle operation status is clear at a glance. At the same time, it is equipped with a remote control operation mode, which is easy and flexible to operate and highly efficient.
4. Durable, safe and reliable
Key structures are all made of high-strength steel or weather-resistant steel, which has good strength, strong corrosion resistance and long service life. Multiple safety protection mechanisms can effectively protect the safety of vehicles and operators.
5. Hydraulic loosening and non-destructive excavation
Equipped with high-pressure water guns for water excavation in special environments, effectively avoiding damage to underground pipelines caused by mechanical excavation.
6. Wastewater circulation to improve efficiency
Some models are equipped with a sewage circulation system, which can filter the sewage sucked into the tank and use it for high-pressure dredging and cleaning operations, which can effectively extend the cleaning operation time, initially realize the separation of mud and water in the sewage suction tank, and improve the solid medium storage capacity of the tank. Reduce the number of transfers, thereby improving work efficiency and reducing operating costs.
